Norwegian Boundary Sediment Plain MPA

Updated conservation advice was produce for the Norwegian Boundary Sediment Plain Nature Conservation MPA in April 2018 and is available in the Conservation Advice section below.

Status: Nature Conservation Marine Protected Area (Nature Conservation MPA)

Located to the east of Scotland in offshore waters, the Norwegian Boundary Sediment Plain MPA lies adjacent to the offshore limit of UK waters.

Site

The Norwegian Boundary Sediment Plain MPA is located to the east of Scotland, adjacent to the offshore limit of UK waters.

A sandy plain in relatively shallow waters, the MPA includes records of the OSPAR Threatened and/or Declining species ocean quahog (Arctica islandica). This thick-shelled clam can live for more than 400 years, making it one of the longest-living creatures on Earth. Like tree rings, the age of ocean quahog can be determined by counting the shell layers that form each year, which also provide information on how our climate has changed over time

More detailed site information can be found in the Summary section below.

Map displaying the Norwegian Boundary Sediment Plain MPA boundary and associated protected feature data. Visit JNCC's MPA Mapper to further view and explore data for this MPA.


Legislation

Legislation behind the designation: Marine and Coastal Access Act (2009)



Protected features

Features Feature Type

Ocean quahog aggregations

(including sands and gravels as their supporting habitat)

Low or limited mobility species

Specific information on the conservation objectives relating to this site is provided in the Conservation Advice section.

The acquisition of new data may result in updates to our knowledge on feature presence and extent within this site. The most up-to-date information is reflected on the map on this page and in JNCC’s MPA mapper and the evidence underpinning this can be viewed in the Evidence section.

Top

Site Timeline

The diagram below is a summary of the key milestones involved in the selection and designation of Norwegian Boundary Sediment Plain Nature Conservation MPA. More detail can be found in the Relevant Documentation section.


Top

Relevant Documentation

The documents referred to below and any other historical documents relating to Norwegian Boundary Sediment Plain Nature Conservation MPA were produced during the selection and designation process and therefore may be out of date. This Site Information Centre is the most up to date source of information for this MPA, and will reflect any additional information gathered since these documents were produced. Information about the Nature Conservation MPA site selection process is available on the JNCC Nature Conservation MPA pages.

These resources are available on JNCC's Resource Hub.

Top

Summary

Last updated: June 2017

The information for this site summary was adapted from documents listed in the Relevant Documentation section and incorporates any further information gathered since these documents were produced.



Site overview

The Norwegian Boundary Sediment Plain MPA is home to a range of animals that live both in and on the sand and gravel habitats such as starfish, crabs, and the long-lived ocean quahog (Arctica islandica); the latter of which is considered to be Threatened and/or Declining across the North-east Atlantic by the OSPAR Commission. Ocean quahog filter food from passing currents and can use a shovel-like foot to bury into the sediment. To escape predators, they can burrow deep into the sediment and live for long periods of time without food or oxygen. Ocean quahog are an important food source for several species of fish including cod. Although they are not specific to one type of habitat, sands and gravels are the ocean quahogs' preferred habitat. The main threat to ocean quahog is disturbance of the sea bed, most often from bottom fishing activities, but licensed activities, such as oil, gas and aggregate extraction, can also directly and indirectly affect this species.

To support the protection of ocean quahog, offshore subtidal sand and gravel habitats are also protected in the context of providing habitat suitable for ocean quahog colonisation. Ocean quahog are typically found buried in medium- to fine-grained sands, sandy mud and silty sand in water depths of 4–400 m. Survey data records from the MPA have confirmed the presence of ocean quahog within the depth range and sediment types in which they are expected to occur.

There are two other MPAs within the Northern North Sea biogeographic region that contain ocean quahog aggregations and their associated habitat as a protected feature. These are East of Gannet and Montrose Fields MPA, which is situated 55 km south-west of the site, and the Firth of Forth Banks Complex MPA, which is 220 km to the south-west. Together these sites increase the replication for protection, and therefore the resilience, of this protected feature in the MPA network. Further detail on the evidence for this Nature Conservation MPA can be found on the Evidence section.

Site location:  Co-ordinates for this Nature Cosnervation MPA can be found in the Designation Order listed in the Relevant Documentation section.

Site area: 164 km2.

Site depth range: The site ranges in depth from 120 m below sea-level to 80 m below sea-level.

Charting Progress 2 Biogeographic Region: Northern North Sea.

Site boundary description: The MPA boundary was drawn to include both surveyed records of ocean quahog and areas of sediments considered suitable for ocean quahog colonisation.

Top

Evidence

Last updated: February 2017

The full overview of the data used to support site identification along with information on confidence in feature presence and extent is available in the Norwegian Boundary Sediment Plain Nature Conservation MPA Data Confidence Assessment. JNCC will be adding relevant data for this MPA to the JNCC MPA mapper when they become available. Some of the data for this MPA have been collected through a JNCC-funded survey. Data from this survey will provide evidence to confirm the presence of the protected features within the site. Other data available for this MPA have been generated through JNCC collection of third-party data and use of predictive seabed habitat mapping information. These data provide direct evidence supporting the presence of the protected features within the site.



Survey and data gathering

  • East of Gannet and Montrose Fields and Norwegian Boundary Sediment Plain seabed monitoring survey (2015) – This survey was a collaboration between JNCC and Marine Scotland Science. Grab samples were collected to form the first point in a monitoring time-series, allowing the JNCC to monitor the rate and direction of long-term change in ocean quahog aggregations.
  • Further evidence that supports our understanding of sediment type in the site have been derived from Particle Size Analysis data that has been sourced from partner organisations, including the British Geological Survey. Operators connected to the oil and gas industry in the Northern North Sea have provided data that support the presence of ocean quahog aggregations within the MPA boundary.



Data analysis reports

  • Cruise Report from the East of Gannet and Montrose Fields and Norwegian Boundary Sediment Plain seabed monitoring survey (2016) – This report details the preliminary field observations of the seabed monitoring survey of East of Gannet and Montrose Fields Nature Conservation MPA and Norwegian Boundary Sediment Plain Nature Conservation MPA conducted by JNCC and Marine Scotland Science. These observations have not been quality assured and so have not been used to support the presence and extent of ocean quahog aggregations and offshore deep-sea mud. Data analysis and reporting is currently underway for the final report and this will be made available when complete.
  • EUSeaMap – Provides supporting information on the presence and extent of offshore subtidal sands and gravels from a predictive seabed habitat map of European waters.



Additional relevant literature

References for further supporting scientific literature consulted during the identification of this site can be found in the Data Confidence Assessment. Please be aware that although these sources contain information in relation to this MPA, they do not necessarily represent the views of JNCC.



Knowledge gaps

If you are aware of any additional information not referred to in the Relevant Documentation section, please contact us.

Top

Conservation Advice

Last updated: April 2018

Updated formal conservation advice is now available for this MPA. Further information on the approach used to develop this advice is available on the Conservation Advice webpage along with a Glossary of Terms used in JNCC conservation advice and a short video explaining how to use the conservation advice packages.

You must refer to this advice if you:

  • Undertake an impact assessment for a plan or project that could impact the site;
  • Provide information for such an assessment;
  • Respond to specific measures to further the conservation objectives for the site; and
  • Consider the need to put new or additional management measures in place.

You may also find it useful to refer to this advice if you:

  • Carry out any other activity that could impact the site.

We will engage with stakeholders to identify any lessons to be learned from customers who have used the advice, to ensure the conservation advice remains fit-for-purpose.

The following table provides an overview of the components of the conservation advice, and provides hyperlinks to each of the products for this MPA. These elements together form JNCC’s formal conservation advice for this site and should be read in conjunction with each other. This advice reflects the most up-to-date evidence held by JNCC (correct as of April 2018).

Document Overview
Background Information Explains the purpose of the advice and when it must be referred to.

Conservation Objectives

Supplementary Advice on the Conservation Objectives (SACO)

The conservation objectives set out the broad ecological aims for the site. JNCC provides supplementary advice in the SACO, which is essential reading to support interpretation of these conservation objectives. It provides further detail and site-specific information for each feature within the site including which of the attributes need to be conserved and which ones recovered.

You can use these documents to assess the impacts of your planned activity on the important attributes of the site.

Please note our current understanding of whether the available evidence indicates that each attribute needs to be recovered or maintained is not provided here. However, links to available evidence for the site are provided and should you require further site-specific information for the site, please contact us

Conservation Advice Statements

These statements provide a summary of the Supplementary Advice on the Conservation Objectives (SACO).

  • Site condition presents our up-to-date understanding of the condition of features within the site;
  • Conservation benefits which the site can provide, these help you understand what is important about the site and why it needs protecting; and
  • Conservation measures which JNCC considers are needed to support achievement of the conservation objectives. These provide clarity around measures needed to support restoration or maintenance of the feature(s) within the site.
Advice on Operations

Provides information on the activities capable of affecting site integrity and therefore achievement of the site’s conservation objectives.

This is a starting point for determining potential management requirements. It does not take into account the intensity, frequency or cumulative impacts from activities taking place. It is simply to advise you of the possible adverse impacts that your activity can have on a MPA’s features.

Use the advice on operations to determine those pressures your activity causes that could harm the habitat and/or species features of the site.

These resources are available on JNCC's Resource Hub.

Top

Activities and Management

Last updated: April 2017

Management status: Progressing towards being well managed

Progress is ongoing with the recommendation for fisheries management proposals to the European Commission and ongoing site condition monitoring work will be required in order to conclude with confidence as to the degree to which the site is moving towards or achieving is conservation objectives.

This site forms part of the UK's contribution to the OSPAR Commission’s network of MPAs. As the UK is a contracting party to the OSPAR Commission, JNCC is committed to ensuring that the OSPAR MPA network is 'well-managed' by 2020.

JNCC considers 'well-managed' to mean the timely progress of an MPA around the 'MPA management cycle'. This involves:

  1. The documentation of appropriate management information – conservation objectives, advice on activities capable of affecting the protected features of a site, and spatial information on the presence and extent of the protected features of a site.
  2. The implementation of management measures – management actions considered necessary to achieve the conservation objectives of a site.
  3. Site condition monitoring programmes – collecting the information necessary to determine progress towards a site's conservation objectives.
  4. Assessment of progress towards conservation objectives – using available information to infer whether or not a site is moving towards or has achieved its conservation objectives.

The sub-sections that follow provide an account of the progress of Norwegian Boundary Sediment Plain Nature Conservation MPA around each of these four stages in the MPA management cycle:



1. The documentation of appropriate management information

  • The conservation objectives and advice on activities capable of affecting the conservation status of the protected feature of this site are available under the Conservation Advice section. Further information is available on our Conservation Advice webpages.
  • Spatial information on the presence and extent of the protected feature of this MPA is available via JNCC's MPA mapper.
  • JNCC is in the process of developing downloadable MPA data packages where appropriate permissions to share datasets are in place.



2. The implementation of management measures

This section details progress towards the implementation of management measures for activities considered capable of affecting the conservation status of the protected features of the site. The protected features of the site are considered to be sensitive to pressures associated with fishing and 'licensable' activities.

Fisheries

  • There is evidence of demersal seine netting and otter trawling within the MPA and UK and non-UK registered vessels have been active in the area.
  • Marine Scotland is the lead authority regarding the implementation of, and compliance with, any measures to managing fishing activity. Further information on progress is available on Marine Scotland’s webpages.

Licensable activities

  • A considerable number of oil and gas developments are currently within the MPA, and the MPA overlaps with a number of license blocks identified by the Department for Business, Energy & Industrial Strategy (formally the Department of Energy and Climate Change) and so may be subject to further oil and gas development in the future.
  • Licensable activities such as oil and gas exploration and production taking place or that may take place within this MPA are managed in accordance with the clauses set out under Section 126 of The Marine & Coastal Access Act (2009). Under this clause, JNCC has a statutory responsibility to advise the regulator on developments that are capable of affecting (other than insignificantly) the protected features of the MPA and that may hinder the achievement of the site's conservation objectives. JNCC considers the existing marine licensing process is sufficient to ensure the management of licensable activities taking place, or that could take place in the future, on the protected features of this MPA.
  • For further information, see Marine Scotland’s Draft MPA Management Handbook and Marine Scotland’s guidance for marine licence applications
  • Further information on JNCC's role in the provision of advice for licensed activities in the UK offshore area is available on JNCCs offshore industry advice webpages



3. Site condition monitoring

A monitoring survey of the MPA took place in 2015. Data was collected to form the first point in a monitoring time-series, allowing for the assessment of the rate and direction of long-term change in ocean quahog aggregations. Further information is provided in the Monitoring section and the survey cruise report (O’Connor 2016).



4. Assessment of progress towards conservation objectives

No long-term condition monitoring data is available to determine whether the MPA is moving towards or has reached its conservation objectives. Further information will be provided under the Assessment section as it becomes available.

Top

Monitoring

Last updated: February 2017

JNCC is currently leading on the development of a strategy for biodiversity monitoring across all UK waters, to include MPA monitoring. For MPAs, data and evidence collected from monitoring activities will be used with the aim to:

  • Enable assessment of condition of the features within sites;
  • Enable assessment of the degree to which management measures are effective in achieving the conservation objectives for the protected features;
  • Support the identification of priorities for future protection and/or management; and,
  • Enable Government to fulfil its national and international assessment and reporting commitments in relation to MPAs and help identify where further action may be required.

Information on monitoring of this MPA will be provided when it becomes available.

Top

Assessment

Last updated: February 2017

Assessments of the condition of designated features in offshore MPAs are required to report against our legal obligations. Ideally these assessments should be based on observed data, and then measured against targets for pre-defined indicators. However, for MPAs in offshore waters we do not always have the appropriate information to be able to do so. This is particularly true for seabed habitats, which are the main type of feature designated for protection in offshore MPAs.

To address these challenges, JNCC has been an active partner in the development of new approaches and tools for the assessment of habitats and species for a variety of national and international status reports.



Conservation Assessment Reports

Under Section 124 of the UK Marine & Coastal Access Act (2009), JNCC is required to report to Ministers every six years on the degree to which the conservation objectives of the protected features of the site have been achieved. Every six years from 2012, the Marine Act requires a report setting out how NCMPAs have performed against their conservation objectives, as well as the effectiveness of the network as a whole. Marine Scotland has published a report setting out progress being made in implementing a Marine Protected Area network that supports the Government’s vision of clean, healthy, safe, productive, biologically diverse marine and coastal environment, managed to meet the long-term needs of nature and people.

Outputs of assessments that feed into Marine Act reporting will also feed into reporting under other obligations.



UK State of the Seas Reports & UK Marine Strategy Part 1

Charting Progress 2 (CP2) published in 2010, is a comprehensive report on the state of the UK seas. It was published by the UK Marine Monitoring and Assessment Strategy (UKMMAS) community which has over 40 member organisations. The report was based on a robust, peer-reviewed evidence base and describes progress made since the publication of Charting Progress in 2005. It provides key findings from UK marine research and monitoring for use by policy makers and others, as we move towards the UK vision of clean, healthy, safe, productive and biologically diverse oceans and seas. The results from CP2 were incorporated into the UK Marine Strategy Part 1: UK Initial Assessment and Good Environmental Status published in 2012 under the UK Marine Strategy Regulations (2010). The UK Marine Strategy Part 1 (2012) also set out the UK’s definition for Good Environmental Status, which could be achieved by meeting a series of environmental targets. JNCC worked with other organisations in the UKMMAS community to develop a series of indicators that were used to assess progress against each of the targets and to report on progress made since 2012. The results of these assessments have been published in the UK Marine Strategy Part 1: UK Updated Assessment and Good Environmental Status in 2019. Detailed evidence used to make these assessments is available via the Marine Online Assessment Tool (MOAT). It also sets out proposals for updated high-level objectives, targets and operational targets to be used for 2018 to 2024, which build on those set in 2012.

It is worth noting the two other parts of the UK Marine Strategy: UK Marine Strategy Part Two: marine monitoring programmes, published in 2014 and UK Marine Strategy Part Three: programme of measures published in 2015. Updates to these will be made in 2020 and 2021 respectively.



OSPAR Quality Status Reports

Many of the assessments in the updated UK Marine Strategy Part 1 2019 were developed and produced in collaboration with other contracting Parties of the OSPAR Convention for the Protection of the North East Atlantic. In 2017 OSPAR Published its Intermediate Assessment (IA2017). The IA 2017 further develops OSPAR’s understanding of the marine environment of the North-East Atlantic and its current status. It demonstrates OSPAR’s progress towards realising its vision of a clean, healthy and biologically diverse North-East Atlantic, used sustainably. IA2017 follows on from OSPAR’s previous holistic assessment, the OSPAR Quality Status Report in 2010 (QSR2010) and in 2000 (QSR2000).



JNCC continues to develop and pilot tools for the assessment of marine habitats and species in offshore waters to improve the quality and transparency of our offshore MPA assessments, and contribute to the monitoring of marine biodiversity in UK waters. These tools cover methods for producing interim assessments of site features and their responses to pressures, as well as developing more robust indicators for determining condition of the features.

Top

  1. Ocean quahog (Arctica islandica) ©Crown Copyright. Image provided by DOENI
  2. Ocean quahog (Arctica islandica) burrowed in sediment ©Crown Copyright. Image provided by DOENI
  3. Sandy swimming crab (Liocarcinus depurator) on Offshore subtidal sands and gravels with many small polychaete worm tubes
  4. Ocean quahog (Arctica islandica)and gurnard (Triglidae) on offshore subtidal sands and gravels ©JNCC/Marine Scotland Science
  5. Soft coral (Alcyonium ssp.) colonised by Zoanthids and feather duster worm (Sabellidae ssp.), as well as a moon snail egg case and many small polychaete worm tubes on rippled Offshore subtidal sands and gravels in East of Gannet and Montrose Fields ©JNCC/Marine Scotland Science
  6. Large anemone (Bolocera tuediae) providing shelter for caridean shrimp (Caridea ssp.) on Offshore subtidal sands and gravels in East of Gannet and Montrose Fields Nature Conservation MPA ©JNCC/Marine Scotland Science
