Dogger Bank MPA

Updated Conservation Advice was produced for Dogger Bank SAC in January 2018 and is available in the Conservation Advice section below.

Status: Special Area of Conservation (SAC)

The Dogger Bank is the largest sandbank in UK waters and extends into both Dutch and German waters. It is home to a variety of species which live both on and within the sandy sediment.



Video

Top

Site

The Dogger Bank is the largest sandbank in UK waters and is home to a variety of species which live both on and within the sandy sediment.  These species include segmented polychaete worms, shrimp-like amphipods, and small clams which burrow into the sand. Animals like hermit crabs, flatfish and starfish also live on top of the sandbank. The location of Dogger Bank in the open sea means that it is exposed to waves, which in turn prevents the shallower parts of the bank having any vegetation growing on it. Long thin silver sandeels can be found on the sides of the sandbank and are food for many seabirds, whales, dolphins and fish such as cod. The Dogger Bank MPA overlaps with a Special Area of Conservation (SAC) that has been identified for the protection of Harbour porpoise – the Southern North Sea SAC. For more information on this MPA, please see the Southern North Sea MPA Site Information Centre.

More detailed site information can be found in the Summary section.

Legislation

Legislation behind the designation: EU Habitats Directive 1992 transposed into UK law by the The Conservation of Offshore Marine Habitats and Species Regulations 2017.



Protected features

Features Feature type

1110 Sandbanks which are slightly covered by seawater all the time

Annex I Habitat*

*For the latest Annex I habitat resource figures, please see the link to the latest Habitats Directive Article 17 reporting in the Assessment section.

Specific information on the conservation objectives relating to this site is provided in the Conservation Advice section.

The acquisition of new data may result in updates to our knowledge on feature presence and extent within this site. The most up to date information are reflected on the map on this page and in JNCC’s MPA mapper and the evidence underpinning this can be viewed in the Evidence section.

Top

Site Timeline

The diagram below is a summary of the key milestones involved in the selection and designation of Dogger Bank. More detail can be found in the Relevant Documentation section.


Top

Relevant Documentation

The documents referred to below and any other historical documents relating to Dogger Bank were produced during the selection and designation process and therefore may be out of date.  This Site Information Centre is the most up-to-date source of information for this MPA and will reflect any additional information gathered since these documents were produced. Information about the SAC site selection process is available on JNCC's SAC webpages.

This relevant documentation is available through JNCC's Resource Hub.

Top

Summary

Last updated: October  2017

The information for this site summary was adapted from documents listed in the Relevant Documentation section and incorporates further information gathered since these documents were produced.



Site overview

The Dogger Bank is the largest single continuous expanse of shallow sandbank in UK waters which was formed by glacial processes before being submerged through sea-level rise. It is located in the Southern North Sea, approximately 150 km  north-east of the Humber Estuary.  The Dogger Bank region is an important location for the North Sea harbour porpoise population and as such, they are included as a non-qualifying feature. Grey and common seals are known to visit the bank and are also included as non-qualifying features at the site.

The southern area of the bank is covered by water seldom deeper than 20 m and extends within the SAC in UK waters down to 35–40 m deep. The bank structure slopes down to greater than 50 m deep in UK, Dutch and German waters. Its location in the open sea exposes the bank to substantial wave energy and prevents the colonisation of the sand by vegetation on the shallower parts of the bank. Sediments range from fine sands containing many shell fragments on top of the bank to muddy sands at greater depths supporting invertebrate communities, characterised by polychaete worms, amphipods and small clams within the sediment, and hermit crabs, flatfish, starfish and brittlestars on the seabed. Sandeels are an important prey resource found at the bank supporting a variety of species including fish, seabirds and cetacean.

Occasional, discrete areas of coarser sediments (including pebbles) were recorded on the bank, dominated by the soft coral Alcyonium digitatum known as dead man's fingers, the bryozoan sea chervil Alcyonidium diaphanum and serpulid worms. The SAC in UK waters adjoins the Dutch and German Dogger Bank SACs. Further detail on the evidence for this SAC can be found on the Evidence section.

Site location: Co-ordinates for this SAC can be found in the Natura 2000 Standard Data Form listed in the previous Relevant Documentation section.

Site area: 12,331 km2 – Dogger Bank is approximately five times the size of the Lake District National Park (2,292 km2).

Site depth range: The Dogger Bank ranges in depth from 13 m to 58 m below sea-level.

Charting Progress 2 Biogeographic Region: Southern North Sea.

Site boundary description: The proposed boundary is a simple shape enclosing the minimum area necessary to ensure protection of the sandbank feature. Dogger Bank gradually extends from sandy sediments in less than 20 m, to deeper water with the greatest slope change around the 45–50 m depth contour. To determine this extent in deeper water, JNCC has used information on the biological communities as well as physical information to assess which areas are part of the feature and host its assemblages, and subsequently, the boundary was defined to include the shallow biological communities.

Top

Evidence

Last updated: October 2017

The full overview of the range of data used to support site identification along with information on confidence in feature presence and extent is available in the Dogger Bank SAC Selection Assessment Document

Some of the data have been collected through JNCC-funded or collaborative surveys. Data from these surveys provide direct evidence confirming the presence of the protected features within the site.



 Survey and data gathering

  • NCC/CEFAS Monitoring programme survey (2014) A pilot monitoring survey was carried out collaboratively, between JNCC and the Centre for Environment, Fisheries and Aquaculture Science (Cefas). The survey gathered 'baseline' data to help inform on the effectiveness of several proposed fishery management areas and to investigate changes in biological communities along a fishing pressure gradient. The survey was intended as a pilot survey to apply the principles of the UK Marine Biodiversity Monitoring R&D (MBMR&D) Programme at the Dogger Bank SAC. The survey report and survey blog are available.
  • JNCC/CEFAS survey of Dogger Bank (2008) – JNCC commissioned this survey to Cefas in order to gather data to support the delineation of a potential site boundary and to characterise the biological communities present.



Data analysis reports

Analyses of data gathered as part of the surveys listed above, as well as other relevant data analysis products, are available via the following reports:

  • Eggleton, J., Murray, J., McIlwaine, P., Mason, C., Noble-James, T., Hinchen, H., Nelson, M., McBreen, F.,Ware,  S. and Whomersley, P. 2017.  Dogger Bank SCI 2014 Monitoring R&D Survey Report, JNCC/Cefas Partnership Report No. 11. – This report describes the findings of a dedicated survey which was carried out between 17 May and 6 June 2014 on the RV Cefas Endeavour (cruise CEND 10/14) to collect evidence to support the development of monitoring options specifically for the Dogger Bank SAC and, more generally, for other comparable offshore shallow sand and coarse sediment habitats.
  • Diesing, M., Ware, S., Foster-Smith, R., Stewart, H., Long, D., Vanstaen, K., Forster, R. and Morando, A. (2009). Understanding the marine environment – seabed habitat investigations of the Dogger Bank offshore draft SAC. JNCC Report No. 429. – Presents the findings of the JNCC contract 'Understanding the marine environment-seabed habitat investigations of the Dogger Bank offshore draft SAC'. It presents detailed geomorphological and biological information pertaining to the Dogger Bank along with a discussion of the underlying context and justification for the proposed dSAC boundary. The report provided some of the necessary information to enable JNCC to advise Defra as to the eligibility of the Dogger Bank as a SAC.



Additional relevant literature

Please be aware that although these sources contain information which is of interest in relation to this MPA, they do not necessarily represent the views of JNCC:

  • Chapman, P. M. (1992). Pollution status of North Sea sediments - an international integrative study. Marine Ecology Progress Series, 91: 313–322 – This paper describes the pollution status of North Sea sediments based on results of sediment testing designed to test various methods (chemical and biological).The authors concluded that sediments offshore and at Dogger Bank are unpolluted. Lesions in bottom fish in such offshore areas cannot be attributed to sediment pollution in these areas, but they could be due to other factors such as exposure of plankton larvae to sea surface microlayer chemical contamination and toxicity.
  • Diesing, M., Stephens D., and Aldridge, J. (2013). A proposed method for assessing the extent of the seabed significantly affected by demersal fishing in the Greater North Sea. ICES Journal of Marine Science, 70:1085-1096. – Explores how vessel monitoring system (VMS) enables high-resolution and large-scale comparisons of fishing and natural disturbance. The authors found that for more than half the seabed in the English sector of the Greater North Sea, disturbance can be attributable to demersal fishing and exceeds natural disturbance based on data from the years 2006 to 2008. The imbalance between natural and fishing disturbance is greatest in muddy substrates and deep circalittoral habitats.
  • ICES (2011). Report of the International Bottom Trawl Survey Working (IBTSWG). ICES CM 2011/SSGESST:06. pp 237. – Produced by an Expert Group under the auspices of the International Council for the Exploration of the Sea (ICES), the report compiles data from several cruises undertaken in the North Sea by different countries and research institutes, aiming to collect data on the distribution and relative abundance, and biological information of commercial fish.
  • Kröncke, I. (2011). Changes in Dogger Bank macrofauna communities in the 20th century caused by fishing and climate. Estuarine, Coastal and Shelf Science, 94: 234–245. – Examines the macrofauna communities on the Dogger Bank from the 1920s, the 1950s and the 1980s to the 2000s and identified five communities with similar in spatial distribution throughout the 20th century but differed in the abundance of dominant species. Both fishing impact and climate change are hypothesised as explaining the changes in the Dogger Bank macrofauna communities.
  • Wieking, G. and Kröncke, I. (2003). Macrofaunnal communities of the Dogger Bank (Central North Sea) in the late 1990: spatial distribution, species composition and trophic structure. Helgoland Marine Research, 57: 34–16. – Describes the macrofauna composition at 28 stations on the Dogger Bank in 1996–1998. The authors found that five communities could be distinguished depending on the influence of different water masses, depth, type of sediment and food availability. The importance of sand lickers in the shallowest parts of the Dogger Bank hints at an important contribution of benthic primary production to the nutritional and energetic needs of the benthic community.



Knowledge gaps

If you are aware of any additional information not referred to in the Relevant Documentation section or above, please contact us.

Top

Conservation Advice

Last updated: January 2018

Updated formal conservation advice for this MPA was produced in January 2018.  Further information on the approach used to develop this advice is available on our Conservation Advice webpage along with a Glossary of Terms used in JNCC conservation advice and a short video explaining how to use the conservation advice packages.

You must refer to this advice if you:

  • undertake a Habitats Regulation Assessment (HRA) for a plan or project that could impact the site;
  • provide information for a HRA;
  • respond to specific measures to support delivery of the conservation objectives for the site; and
  • consider the need to put new or additional management measures in place.

You may also find it useful to refer to this advice if you:

  • carry out any other activity that could impact the site.

We will engage with stakeholders to identify any lessons which JNCC can learn from customers who have used the advice, with a view to continuing to ensure it is fit-for-purpose.

The following table provides an overview of the components of the conservation advice and provides hyperlinks to each of the products for this MPA.  These elements together form JNCC’s formal conservation advice for this site and should be read in conjunction with each other.  This updated advice replaces the previous Regulation 18 package for the site.  This advice reflects the most up-to-date evidence held by JNCC (correct as of January 2018).

Document Overview
Background Information Explains the purpose of the advice and when it must be referred to.

Conservation Objectives

Supplementary Advice on the Conservation Objectives (SACO)

The conservation objectives set out the broad ecological aims for the site. JNCC provides supplementary advice in the SACO which is essential reading to support the interpretation of these conservation objectives. It provides further detail and site-specific information for each feature within the site, including which of the attributes need to be conserved and which ones recovered.

You can use these documents to assess the impacts of your planned activity on the important attributes of the site.
Conservation Advice Statements

These statements provide a summary of the Supplementary Advice on the Conservation Objectives (SACO).

  • Site condition presents our up-to-date understanding of the condition of features within the site;
  • Conservation benefits which the site can provide, these help you understand what is important about the site and why it needs protecting; and
  • Conservation measures which JNCC considers are needed to support the achievement of the conservation objectives. These provide clarity around measures needed to support restoration or maintenance of the feature(s) within the site.
Advice on Operations

Provides information on the activities capable of affecting site integrity and therefore achievement of the site’s conservation objectives.

This is a starting point for determining potential management requirements. It does not take into account the intensity, frequency or cumulative impacts from activities taking place. It is simply to advise you of the possible adverse impacts that your activity can have on a MPA’s features.

Use the advice on operations to determine those pressures your activity causes that could harm the habitat and/or species features of the site.

These documents are available on JNCC's Resource Hub.

Top

Activities and Management

Last updated: October 2017

Management status: Progressing towards being well managed.

Progress is ongoing with the recommendation of fisheries management proposals to the European Commission. Ongoing site condition monitoring work will be required to conclude with confidence as to the degree to which the site is moving towards or achieving its conservation objectives. A baseline condition monitoring survey was undertaken in 2014 (Eggleton et al. 2017).

This site forms part of the UK's contribution to the OSPAR Commission's network of MPAs, Europe’s Natura 2000 network and the Emerald Network established under the Bern Convention. As the UK is a contracting party to the OSPAR Commission, JNCC is committed to ensuring that the OSPAR MPA network is 'well-managed' by 2020.

JNCC considers 'well-managed' to mean the timely progress of an MPA around the 'MPA management cycle. This involves:

  1. The documentation of appropriate management information – conservation objectives, advice on activities capable of affecting the protected features of a site, and spatial information on the presence and extent of the protected features of a site.
  2. The implementation of management measures – management actions considered necessary to achieve the conservation objectives of a site.
  3. Site condition monitoring programmes – collecting the information necessary to determine progress towards a sites conservation objectives.
  4. Assessment of progress towards conservation objectives – using available information to infer whether or not a site is moving towards or has achieved its conservation objectives.

The sub-sections that follow provide an account of the progress of Dogger Bank SAC around each of the four stages in the MPA management cycle.



1. The documentation of appropriate management information

  • The conservation objectives and advice on activities capable of affecting the conservation status of the protected feature of this site are available under the Conservation Advice section. Further information is available on our Conservation Advice webpage.
  • Spatial information on the presence and extent of the protected feature of this MPA is available via JNCC’s MPA mapper.
  • JNCC is in the process of developing downloadable MPA data packages where appropriate permissions to share datasets are in place.



2. The implementation of management measures

This section details progress towards the implementation of management measures for activities considered capable of affecting the conservation status of the protected feature of the site. The protected feature of the site is considered to be sensitive to pressures associated with fishing and 'licensable' activities.

Fisheries

  • There is evidence of mobile demersal effort within the MPA and UK and non-UK registered vessels have been active in the area.
  • Dogger Bank extends across the UK, Dutch, German and Danish sectors of the North Sea and both the Netherlands and Germany have also designated their areas of the bank as SACs. The respective Member States governments have been working through the Dogger Bank Steering Group to develop fisheries measures recommendations. Stakeholders have been actively involved in this process through the North Sea Regional Advisory Council (RAC). A fisheries joint management proposal was agreed in early 2017. The Joint Recommendation was finalised and submitted to the European Commission in June 2019, but a delegated Act is yet to be drafted.
  • The Marine Management Organisation is the lead authority regarding the implementation of, and compliance with, any measures to managing fishing activity. Further information on progress is available via MMO’s webpage.

Licensable activities

  • At the moment, a considerable number of oil and gas developments overlap this MPA, including many fields, pipelines, wells and associated infrastructure. Decommissioning activities in relation to these activities are likely to take place in the near future.
  • Renewables – Creyke Beck and Teesside A and B wind farms were granted consent by the Secretary of State in 2015 and pre-construction activities started in 2015.
  • Aggregate extraction – a proposal for licensing 2 areas for aggregate extraction overlaps with this MPA. Aggregate extraction activity is not thought to be underway at the current time but these areas may be subject to activity in the future.
  • Any future proposals related to licensable activities would have to comply with Regulation 28 (Protection of European offshore marine sites and European sites) of The Conservation of Offshore Marine Habitats and Species Regulations 2017.
  • JNCC's conservation advice supports the consents process by setting out the conservation objectives for the protected feature of this MPA and advice on activities that may result in pressures to which the protected feature is considered sensitive. Further information on JNCC’s role in the provision of advice for licensed activities in the UK offshore area is available on JNCC’s offshore industry advice webpages

Telecommunications cables

  • Four telecommunications cables currently cross through the MPA.
  • Cables are largely an unregulated activity in offshore waters depending upon the type of cable being laid (or maintained), where it is being laid between and whether the cable is part of a larger development (which may be regulated). Any cable not directly associated with an energy installation does not require a marine license beyond the 12 nautical miles limit.
  • JNCC encourages early discussion from operators regarding any plans related to new or existing cables, and encourages the undertaking of non-statutory environmental impact assessments for new or existing cable projects to assess their effect on the protected features of the MPA.



3. Site conditioning monitoring

A baseline condition monitoring survey was undertaken in 2014 (reported in Eggleton et al. 2017). Further information is provided in the Monitoring section.



4. Assessment of progress towards conservation objectives

No long-term condition monitoring data are available to determine whether the MPA is moving towards or has reached its conservation objectives. The site has a 'recover' conservation objective based on the findings of a vulnerability assessment (i.e. exposure to pressures from ongoing activities to which the protected feature of the site is considered sensitive). Monitoring data would improve our confidence in this assessment. Further information will be provided under the Assessment section as it becomes available.

Top

Monitoring

Last updated: October 2017

JNCC is currently leading on the development of a strategy for biodiversity monitoring across all UK waters, to include MPA monitoring. For MPAs, data and evidence collected from monitoring activities will aim to:

  • Enable assessment of the condition of the features within sites;
  • Enable assessment of the degree to which management measures are effective in achieving the conservation objectives for the protected features;
  • Support the identification of priorities for future protection and/or management; and,
  • Enable Government to fulfil its national and international assessment and reporting commitments in relation to MPAs and help identify where further action may be required.

A research and development monitoring survey of the Dogger Bank SAC was conducted in May/June 2014. The aims of the survey were to:

  • Collect data inside and outside of proposed fisheries management measures to establish the first point in a time series to monitor changes in the habitats over time;
  • Collect data over a gradient of surface abrasion to better understand the relationship between surface abrasion and the habitats in the MPA; and
  • Conduct a gear comparison study to compare different grab samplers which have been used to collect macrofaunal and sediment data in the MPA to understand how comparable different datasets are.

Details of the cruise report and data analysis report will be provided in the Evidence section.

Top

Assessment

Last updated: October 2017

Assessments of the condition of designated features in offshore MPAs are required to report against our legal obligations. Ideally these assessments should be based on observed data, and then measured against targets for pre-defined indicators. However, for MPAs in offshore waters we do not always have the appropriate information to be able to do so. This is particularly true for seabed habitats, which are the main type of feature designated for protection in offshore MPAs.

To address these challenges, JNCC has been an active partner in the development of new approaches and tools for the assessment of habitats and species for a variety of national and international status reports.



Conservation Assessment Reports

Every six years, Member States of the European Union are required (by Article 17 of the Directive) to report on implementation of the Habitats Directive. The latest report on the Conservation Status of Annex I habitats and Annex II species on the Habitats Directive was submitted by the UK in 2019 and provided an assessment of the conservation status of relevant habitats and species within UK marine waters during period 2013–2018; information on the condition of features within SACs have made a contribution to this report.



UK State of the Seas Reports & UK Marine Strategy Part 1

Charting Progress 2 (CP2) published in 2010, is a comprehensive report on the state of the UK seas. It was published by the UK Marine Monitoring and Assessment Strategy (UKMMAS) community which has over 40 member organisations. The report was based on a robust, peer-reviewed evidence base and describes progress made since the publication of Charting Progress in 2005. It provides key findings from UK marine research and monitoring for use by policy makers and others, as we move towards the UK vision of clean, healthy, safe, productive and biologically diverse oceans and seas. The results from CP2 were incorporated into the UK Marine Strategy Part 1: UK Initial Assessment and Good Environmental Status published in 2012 under the UK Marine Strategy Regulations (2010). The UK Marine Strategy Part 1 (2012) also set out the UK’s definition for Good Environmental Status, which could be achieved by meeting a series of environmental targets. JNCC worked with other organisations in the UKMMAS community to develop a series of indicators that were used to assess progress against each of the targets and to report on progress made since 2012. The results of these assessments have been published in the UK Marine Strategy Part 1: UK Updated Assessment and Good Environmental Status in 2019. Detailed evidence used to make these assessments is available via the Marine Online Assessment Tool (MOAT). It also sets out proposals for updated high-level objectives, targets and operational targets to be used for 2018 to 2024, which build on those set in 2012.

It is worth noting the two other parts of the UK Marine Strategy: UK Marine Strategy Part Two: marine monitoring programmes, published in 2014 and UK Marine Strategy Part Three: programme of measures published in 2015. Updates to these will be made in 2020 and 2021 respectively.



OSPAR Quality Status Reports

Many of the assessments in the updated UK Marine Strategy Part 1 2019 were developed and produced in collaboration with other contracting Parties of the OSPAR Convention for the Protection of the North East Atlantic. In 2017 OSPAR Published its Intermediate Assessment (IA2017). The IA 2017 further develops OSPAR’s understanding of the marine environment of the North-East Atlantic and its current status. It demonstrates OSPAR’s progress towards realising its vision of a clean, healthy and biologically diverse North-East Atlantic, used sustainably. IA2017 follows on from OSPAR’s previous holistic assessment, the OSPAR Quality Status Report in 2010 (QSR2010) and in 2000 (QSR2000).



JNCC continues to develop and pilot tools for the assessment of marine habitats and species in offshore waters to improve the quality and transparency of our offshore MPA assessments, and contribute to the monitoring of marine biodiversity in UK waters. These tools cover methods for producing interim assessments of site features and their responses to pressures, as well as developing more robust indicators for determining condition of the features.
