|Updated conservation advice was produced for the Fulmar MCZ in February 2018 and is available in the Conservation Advice section below.|
Status: Marine Conservation Zone (MCZ)
Fulmar MCZ is an offshore site, 50–100 m deep, located approximately 224 km from the Northumberland coast.
Located approximately 224 km from the Northumberland Coast, Fulmar MCZ is an offshore site, 50–100 m deep. The seabed of Fulmar MCZ is composed of subtidal mud and subtidal sand, with patches of subtidal mixed sediment. The habitats the MCZ protects are important resources for marine animals, providing food, spawning areas and shelter. Burrowing anemones and brittlestars are found at the site as well as slender sea-pens that protrude from the surface of the mud. Ocean quahog, an OSPAR threatened and/or declining species is also present, often entirely buried in the sand with a small tube extending to the surface for breathing and feeding.
More detailed site information can be found in the Summary section.
Map displaying the Fulmar MPA boundary and associated protected feature data. Visit JNCC's MPA Mapper to further view and explore data for this MPA.
Legislation behind the designation: Marine and Coastal Access Act (2009)
|EUNIS Code: Protected Feature||Feature Type||General Management Approach (to achieve conservation objective)
|A5.2: Subtidal sand||Broad-scale habitat||Maintain in favourable condition|
|A5.3: Subtidal mud||Broad-scale habitat||Maintain in favourable condition|
|A5.4: Subtidal mixed sediments||Broad-scale habitat||Maintain in favourable condition|
|Ocean Quahog (Arctica islandica)||Species Feature Of Conservation Importance||Maintain in favourable condition|
Specific information on the conservation objectives relating to this site is provided in the Conservation Advice section.
The acquisition of new data may result in updates to our knowledge on feature presence and extent within this site. The most up-to-date information is reflected on the map at the top of the page and in JNCC's MPA mapper, with the underpinning evidence available in the Evidence section.
The diagram below is a summary of the key milestones involved in the selection and designation of Fulmar MCZ. More information on the site's milestones can be found within the Relevant Documentation section and in annex three of JNCC's advice on offshore MCZs considered for consultation in 2015.
The document listed below and any other historical documents relating to Fulmar MCZ were produced during the selection and designation process and therefore may be out of date. This site information centre is the most up-to-date source of information for Fulmar MCZ, and will reflect any additional information gathered since these documents were produced. Further information about the MCZ site selection process and historic MCZ advice is available on JNCC's MCZ webpages.
- Fulmar MCZ Designation Order – The official description of the site designation under the Marine and Coastal Access Act 2009. The designation order includes boundary coordinates, conservation objectives and a list of the designated features. More information on the Designation Order, including a designation map and factsheet is available on Defra's website.
- JNCC's formal conservation advice for this site is available in the Conservation Advice section below.
Last updated: October 2017
This site summary was adapted from the MCZ Site Report and incorporates any information gathered since this document was produced. Please refer to this document for further details and information sources.
Fulmar MCZ is located approximately 224 km offshore of the Northumberland coast in the north-east of England, close to Swallow Sand MCZ and North East of Farnes Deep MCZ. The seabed in the MCZ is predominantly subtidal mud, with small patches of other sediments. Burrowing tube anemones (Cerianthus lloydii), brittlestars (including Amphuria filiformis and Ophiura albida) and sea potatoes (Echinocardium cordatum) are found living on the sediments at Fulmar MCZ. Sea-pens such as the slender sea-pen (Virgularia mirabilis) are also present. Fulmar MCZ is also home to a wide variety of worms that live within the sediment, which are an important food source for many other animals, including commercial fish species.
The MCZ currently has four designated features: subtidal mud, subtidal sand, subtidal mixed sediments and ocean quahog (Arctica islandica). Ocean quahogs are a feature of conservation importance, and are also included on the OSPAR list of Threatened and/or Declining Species & Habitats. This bivalve is a long-lived species (over 500 years) with a very slow growth rate, taking up to 50 years to reach market size. They are thought to reach sexual maturity between 5–7 years, although this is dependent on locality and growth rates. The spawning period can vary also depending on location. Recent studies have found the population of ocean quahog in the North Sea has declined in abundance, which has been linked to the impacts of human activities on the seabed.
Fulmar MCZ was originally recommended by the Net Gain regional project in 2011 to help meet the targets of protecting subtidal coarse sediment and subtidal sand broad-scale habitat features, and for the presence of ocean quahog. The presence of these features in the site was based on a modelled habitat map developed by the UKSeaMap project in 2010 and ground-truthing carried out using data from British Geological Survey (BGS) and historical surveys (1902–2011).
Since the site was recommended, more data for Fulmar MCZ have been collected through additional data analysis and another site survey in 2012. Ground-truthing confirmed the presence of subtidal mud and subtidal mixed sediments broad-scale habitats in the site and formed the basis for a new modelled habitat map to revise the extent of subtidal sand and subtidal coarse sediment at the site. The survey, along with other data sourced confirmed the presence of ocean quahog at the site. Community analysis and biotope identification has also been conducted. Further detail on the evidence for this MCZ can be found in the Evidence section.
Site location: Co-ordinates for this MCZ can be found in the designation order listed in the Relevant Documentation section.
Site area: 2,437 km2, a size similar to the county of Cheshire (2,343 km2).
Site depth range: 50–100 m.
Charting Progress 2 biogeographic region: Northern North Sea.
Site boundary description: The site is a simple polygon with boundary lines running north to south and east to west in line with the guidance provided by the MCZ project's Ecological Network Guidance. The boundary of Fulmar MCZ was developed by the Net Gain regional project and has not changed since it was recommended in 2011. The site boundary was guided by information on fishing intensity from international fishing fleets and infrastructure present on the seabed.
Last updated: October 2017
For a full overview of the data used to support site identification and information on confidence in feature presence and extent see JNCC's Tranche Two MCZ pre-consultation and post-consultation advice. References to the scientific literature consulted during the identification of this site can be found on JNCC's MCZ webpages.
The data for the Fulmar MCZ were collected primarily through JNCC-funded or collaborative surveys, with other data obtained through other data sourcing. The data gathered provide direct evidence confirming the presence of the protected features within the site. Additional survey data will be added to JNCC's MPA mapper in due course.
Survey and data gathering
- Fulmar MCZ MB0120 survey (2012) – JNCC collaborated with Cefas on an MCZ site verification survey to Fulmar MCZ, funded by the Defra data collection fund. Video, images, acoustic data and grab samples were collected across the site.
Data analysis reports
Analyses of data gathered as part of the survey listed above, as well as other relevant data analysis products, are available in the following reports:
- EUSeaMap – Provides supporting information on the presence and extent of Subtidal sand, Subtidal mud and Subtidal mixed sediments from a predictive seabed habitat map of European waters.
- Mapping seabed sediments of the Fulmar rMCZ (2015) – Using the Fulmar MCZ survey data, JNCC contracted British Geological Survey to carry out particle size analysis to identify the sediments within the MCZ. The results verified the presence of Subtidal sand, Subtidal mud and Subtidal mixed sediments within Fulmar MCZ.
- Fulmar rMCZ Post-survey Site Report (2015). - Cefas undertook analysis of the data collected on the Fulmar MCZ survey (2012) to produce a summary report. The data, analysed as part of the MB0120 Defra contract, led to the creation of a revised habitat map that has been used to inform the presence of broad-scale habitats within the MCZ.
- Community analysis of Fulmar MCZ data (2014) – JNCC undertook a community analysis of the grab and video data from the Fulmar MCZ survey (2012) to establish the biotopes present within the MCZ. The results showed that the follow biotopes were present at the site:
- SS.SMu.OMu.PjefThyAfil (A5.376): Paramphinome jeffreysii, Thyasira spp. and Amphiura filiformis in offshore circalittoral sandy mud;
- S.SMu.CSaMu.VirOphPmax (A5.354): Virgularia mirabilis and Ophiura spp. with Pecten maximus on circalittoral sandy or shelly mud; and
- SS.SMx.CMx (A5.44x): Circalittoral mixed sediments, no matching biotope.
Additional relevant literature
References for further supporting scientific literature consulted during the identification of this site can be found in the annexes of our advice. Please be aware that although these sources contain information in relation to this MPA, they do not necessarily represent the views of JNCC.
If you are aware of any additional data not listed here or scientific papers relevant to this site, please contact us.
Last updated: February 2018
Updated formal conservation advice is now available for this MPA. Further information on the approach used to develop this advice is available on our 'Conserving MPAs' webpage along with a Glossary of Terms used in JNCC's conservation advice and a short video explaining how to use the conservation advice packages.
You must refer to this advice if you:
- undertake an MCZ assessment for a plan or project that could impact the site;
- provide information for such an assessment;
- respond to specific measures to further the conservation objectives for the site; and
- consider the need to put new or additional management measures in place.
You may also find it useful to refer to this advice if you:
- carry out any other activity that could impact the site.
We will engage with stakeholders to identify any lessons to be learned from customers who have used the advice, to ensure the conservation advice remains fit-for-purpose.
The following table provides an overview of the components of the conservation advice, and provides hyperlinks to each of the products for this MPA. These elements together form JNCC’s formal conservation advice for this site and should be read in conjunction with each other. This advice reflects the most up-to-date evidence held by JNCC (correct as of February 2018).
|Background Information||Explains the purpose of the advice and when it must be referred to.|
The conservation objectives set out the broad ecological aims for the site. JNCC provides supplementary advice in the Supplementary Advice on the Conservation Objectives (SACO), which is essential reading to support interpretation of these conservation objectives. It provides further detail and site-specific information for each feature within the site including which of the attributes need to be conserved and which ones recovered.
You can use these documents to assess the impacts of your planned activity on the important attributes of the site.
Please note our current understanding of whether the available evidence indicates that each attribute needs to be recovered or maintained is not provided here. However, links to available evidence for the site are provided and should you require further site-specific information for the site, please contact us.
|Conservation Advice Statements||
These statements provide a summary of the Supplementary Advice on the Conservation Objectives (SACO).
|Advice on Operations||
Provides information on the activities capable of affecting site integrity and therefore achievement of the site’s conservation objectives.
This is a starting point for determining potential management requirements. It does not take into account the intensity, frequency or cumulative impacts from activities taking place. It is simply to advise you of the possible adverse impacts that your activity can have on a MPA’s features.Use the advice on operations to determine those pressures your activity causes that could harm the habitat and/or species features of the site.
These documents are all available on JNCC's Resource Hub.
Activities and Management
Last updated: October 2017
Management status: Progressing towards being well managed
Progress is ongoing with fisheries management options being developed. Whilst the vulnerability assessment conducted for this site suggests it may be achieving or moving towards its conservation objectives, directed site condition monitoring data are needed to improve our confidence in this assessment.
This site forms part of the UK's contribution to the OSPAR Commission's network of MPAs. As the UK is a contracting party to the OSPAR Commission, JNCC is committed to ensuring that the OSPAR MPA network is 'well-managed' by 2020.
JNCC considers 'well-managed' to mean the timely progress of an MPA around the 'MPA management cycle'. This involves:
- The documentation of appropriate management information – conservation objectives, advice on activities capable of affecting the protected features of a site, and spatial information on the presence and extent of the protected features of a site.
- The implementation of management measures – management actions considered necessary to achieve the conservation objectives of a site.
- Site condition monitoring programmes – collecting the information necessary to determine progress towards a site's conservation objectives.
- Assessment of progress towards conservation objectives – using available information to infer whether or not a site is moving towards or has achieved its conservation objectives.
The sub-sections that follow provide an account of the progress of Fulmar MCZ around each of these four stages in the MPA management cycle:
1. The documentation of appropriate management information
- The conservation objectives and advice on activities capable of affecting the conservation status of the protected feature of this site are available in the Conservation Advice section. Further information is available on our 'Conserving MPAs' webpage.
- Spatial information on the presence and extent of the protected feature of this MPA is available via JNCC's MPA mapper.
- JNCC is in the process of developing downloadable MPA data packages with appropriate permissions to share datasets in place.
2. The implementation of management measures
This section details progress towards the implementation of management measures for activities considered capable of affecting the conservation status of the protected features of the site. The protected features of the site are considered to be sensitive to pressures associated with fishing, 'licensable' activities and telecommunications cables.
- Vessel monitoring data indicate that there is no fishing activity within the MCZ. If fishing activity takes place in the future, management proposals would need to be developed in line with JNCC's and Natural England's fisheries advice.
- Further information is available on the Marine Management Organisation's webpages.
- A considerable number of oil and gas developments take place within this MPA, including many fields, pipelines, wells and associated infrastructure.
- Licensable activities such as oil and gas exploration and production taking place or that may take place within this MPA are managed in accordance with the clauses set out under Section 127 of The Marine & Coastal Access Act (2009). Under this clause, JNCC has a statutory responsibility to advise the regulator on developments that are capable of affecting (other than insignificantly) the protected features of the MPA and that may hinder the achievement of the site's conservation objectives. JNCC considers the existing marine licensing process is sufficient to ensure the management of licensable activities taking place, or that could take place in the future, on the protected features of this MPA.
- For further information, please see The Marine Management Organisation's guidance on marine conservation zones and marine licensing.
- Further information on JNCC's role in the provision of advice for licensed activities in the UK offshore area is available on JNCC's offshore industry advice webpages.
- One telecommunications cable currently crosses through the MPA.
- Cables are largely an unregulated activity in offshore waters depending upon the type of cable being laid (or maintained), where it is being laid between and whether the cable is part of a larger development (which may be regulated). Any cable not directly associated with an energy installation does not require a marine license beyond the territorial limit.
- JNCC encourages early discussion from operators regarding any plans related to new or existing cables, and encourages the undertaking of non-statutory environmental impact assessments for new or existing cable projects to assess their effect on the protected features of the MPA.
3. Site condition monitoring
Site condition monitoring surveys are yet to take place within this MPA. Further information will be made available in the Monitoring section in due course.
4. Assessment of progress towards conservation objectives
No long-term condition monitoring data are available to determine whether the MPA is moving towards or has reached its conservation objectives. The site has a ‘maintain’ conservation objective based on the findings of a vulnerability assessment (assessing the exposure to activities associated with pressures to which the protected features of the site are considered sensitive). This suggests the site may already be achieving or moving towards its conservation objectives. Site condition monitoring data would improve our confidence in this assessment. Further information will be provided in the Assessment section as it becomes available.
Last updated: October 2017
JNCC is currently leading on the development of a strategy for biodiversity monitoring across all UK waters which includes the monitoring of MPAs. For MPAs, data and evidence collected from monitoring activities will be used with the aim to:
- Enable assessment of condition of the features within sites;
- Enable assessment of the degree to which management measures are effective in achieving the conservation objectives for the protected features;
- Support the identification of priorities for future protection and/or management; and
- Enable the government to fulfil its national and international assessment and reporting commitments in relation to MPAs and help identify where further action may be required.
Information on monitoring of Fulmar MCZ will be provided when it becomes available.
Last updated: October 2017
Assessments of the condition of designated features in offshore MPAs are required to report against our legal obligations. Ideally these assessments should be based on observed data, and then measured against targets for pre-defined indicators. However, for MPAs in offshore waters we do not always have the appropriate information to be able to do so. This is particularly true for seabed habitats, which are the main type of feature designated for protection in offshore MPAs.
To address these challenges, JNCC has been an active partner in the development of new approaches and tools for the assessment of habitats and species for a variety of national and international status reports.
Conservation Assessment Reports
Under Section 124 of the UK Marine & Coastal Access Act (2009), JNCC is required to report to Ministers every six years on the degree to which the conservation objectives of the protected features of Marine Conservation Zones (MCZs) have been achieved. Every six years from 2012, the Marine Act requires a report setting out how MCZs have performed against their conservation objectives, as well as the effectiveness of the network as a whole.
To date, three reports have been published, each setting out progress being made in implementing a Marine Protected Area network, covering the following areas:
- English inshore and English and Northern Irish offshore MPAs
- Welsh inshore and offshore MPAs
- Scottish inshore and offshore MPAs
Outputs of assessments that feed into Marine Act reporting also feed into reporting under other obligations.
Charting Progress 2 (CP2) published in 2010, is a comprehensive report on the state of the UK seas. It was published by the UK Marine Monitoring and Assessment Strategy (UKMMAS) community which has over 40 member organisations. The report was based on a robust, peer-reviewed evidence base and describes progress made since the publication of Charting Progress in 2005. It provides key findings from UK marine research and monitoring for use by policy makers and others, as we move towards the UK vision of clean, healthy, safe, productive and biologically diverse oceans and seas. The results from CP2 were incorporated into the UK Marine Strategy Part 1: UK Initial Assessment and Good Environmental Status published in 2012 under the UK Marine Strategy Regulations (2010). The UK Marine Strategy Part 1 (2012) also set out the UK’s definition for Good Environmental Status, which could be achieved by meeting a series of environmental targets. JNCC worked with other organisations in the UKMMAS community to develop a series of indicators that were used to assess progress against each of the targets and to report on progress made since 2012. The results of these assessments have been published in the UK Marine Strategy Part 1: UK Updated Assessment and Good Environmental Status in 2019. Detailed evidence used to make these assessments is available via the Marine Online Assessment Tool (MOAT). It also sets out proposals for updated high-level objectives, targets and operational targets to be used for 2018 to 2024, which build on those set in 2012.
It is worth noting the two other parts of the UK Marine Strategy: UK Marine Strategy Part Two: marine monitoring programmes, published in 2014 and UK Marine Strategy Part Three: programme of measures published in 2015. Updates to these will be made in 2020 and 2021 respectively.
OSPAR Quality Status Reports
Many of the assessments in the updated UK Marine Strategy Part 1 2019 were developed and produced in collaboration with other contracting Parties of the OSPAR Convention for the Protection of the North East Atlantic. In 2017 OSPAR Published its Intermediate Assessment (IA2017). The IA 2017 further develops OSPAR’s understanding of the marine environment of the North-East Atlantic and its current status. It demonstrates OSPAR’s progress towards realising its vision of a clean, healthy and biologically diverse North-East Atlantic, used sustainably. IA2017 follows on from OSPAR’s previous holistic assessment, the OSPAR Quality Status Report in 2010 (QSR2010) and in 2000 (QSR2000).
JNCC continues to develop and pilot tools for the assessment of marine habitats and species in offshore waters to improve the quality and transparency of our offshore MPA assessments, and contribute to the monitoring of marine biodiversity in UK waters. These tools cover methods for producing interim assessments of site features and their responses to pressures, as well as developing more robust indicators for determining condition of the features.
- Ocean Quahog in sandy sediment, © Becky Hitchin
- Slender sea pens (Virgularia mirabilis) in muddy sediment with worm casts (Arenicola marina), © JNCC/Cefas
- Common sea urchin (Echinus esculentus) and silty sediment together with the hydroid Corymorpha nutans, © JNCC/Cefas
- Horse mussels (Modiolus modiolus) in muddy sediment with a hag fish (Myxine glutinosa) swimming away, © JNCC/Cefas
- Northern stone crab (Lithodes maja) on sediment, © JNCC/Cefas
- Sand with empty shells and shell fragments, © JNCC/Cefas
- Lemon sole (Microstomus kitt) on mud, © JNCC/Cefas
- Sandy mud with small cobbles and pebbles with shell fragments, © JNCC/Cefas
